Product Introduction
C50 Plus is equipped with a powerful 1D & 2D barcode scanner, 3G/4G, WiFi, BT, GPS, and ergonomic grip design, the C50 Plus allows you to quickly and accurately scan barcodes and update inventory records on the spot. Its ergonomic design provides comfortable handling during prolonged use, reducing the risk of hand fatigue and increasing productivity.
Product Advantage
Powerful Performance and Android 9.0 OS: The C50 Plus Handheld Barcode Scanner PDA boasts a robust 4G connectivity and runs on the latest Android 9.0 operating system, ensuring smooth multitasking and app compatibility. Its Quad-core processor delivers exceptional speed and performance for efficient data processing.
Versatile Barcode Scanning Capabilities: With advanced 1D and 2D barcode scanning technology, the C50 Plus can accurately read barcodes from various surfaces and angles, enhancing productivity in inventory management, logistics, and retail applications.
Rugged and Durable Design: Built to withstand harsh environments, the C50 Plus is IP65-rated, providing resistance against dust and water. Its rugged construction ensures durability even in demanding work settings, making it suitable for outdoor and industrial use.
Enhanced Connectivity and Data Capture: Equipped with Bluetooth and Wi-Fi connectivity, the PDA enables seamless data transfer and communication. Additionally, it comes with a built-in camera for image capture and NFC capability for contactless data exchange, expanding its functionality for diverse business needs.
Technical Parameters
Specification
CPU | ARM Cortex-A53 64 bit Octa-core 2.0GHz |
Operation System | Android 9.0 |
Memory | 2GB RAM + 16GB ROM 4GB RAM + 64GB ROM (Optional) |
Expansion Slot | Mini SD card (utmost support 32G), Micro SD slot |
Display | 5.0' MIPI interface, HD_IPS (HD720 x 1280) |
Touch Panel | Industrial touch screen (support glove touch) |
Camera | 13MP autofocus with LED fill light |
Imager Window | Corning Gorilla |
Keyboard | 1 anti-wear button, 2 industrial touch buttons, side buttons 5 |
Battery | 4.35V 5000mAh Lithium polymer battery |
Audio Frequency | Built-in microphone |
Prompt | Vibration Tip/LED Tip/Audio Tip |
Vibration Motor | Built-in programmable vibration motor |
Size & Weight | 152.5 mm x 76 mm x 17 mm 250g |
4G/3G/2G | 2G: 900/1800,CDMA2000 |
3G: B1/B34/B39,EVD0 | |
4G: B1/B2/B3/B4/B5/B7/B8/B12/B20/B38/B39B40/B41 | |
WLAN | Wi-Fi 802.11b/g/n |
WPAN | Bluetooth 4.0 |
1D Scanning | UPC-A, UPC-E, EAN-13, EAN-8, 39 code, Cross 25 code, Matrix 25 code, code bar 128, UCC/EAN 128(GS1-128), ISBT 128, 93 code, China Post, China Finance, GS1 Data Bar, GS1 Data Bar Truncated 3, GS1 Data Bar Limited, GS1 Data Bar Expanded |
2D Scanning | Coda block A, Coda block F, PDF417, MicroPDF417, QR Code, Data Matrix, Maxi Code, Chinese Sensible(Han Xin) code, Aztec Code, Australian Post, British Post, Canadian Post, China Post, Japanese Post, Korea Post, Netherlands Post, Plant Code, Potent |
GPS | A-GPS |
Infrared Meter Reading | Working frequency 37.9K (Optional) |
Interface | Type-C interface |
Standard | Battery, Adapter, USB cable for power and communication, Hand strap |
Card Slot | 2 SIM card slots, 1 TF card slot, 1 PSAM card slot |
Development Tool | Android SDK +JDK +Eclipse |
Programming Language | Java, C |
Operating Temperature | -27℃ ~ 50℃ |
Storage Temperature | -27℃ ~ 60℃ |
Humidity | 0 ~ 95% |
Drop Specifications | Multiple 1.5m drop to tile over concrete |
Tumble Specifications | Exceeds 500 (0.5m) tumbles |
Sealing | IP67 |
ESD Protection | ±12kV air, ±8kV contact |
Product Uses
Inventory management: Handheld PDA streamline stocktaking, helping businesses efficiently track and manage inventory levels.
Field service operations: PDA aid technicians in diagnosing and fixing issues on-site, improving response time and service quality.
Retail sales: PDA facilitate mobile payments, inventory inquiries, and customer interactions, enhancing the shopping experience.
Logistics and shipping: PDAs assist in real-time package tracking, route optimization, and delivery confirmation for smoother logistics operations.
Product Video
https://www.youtube.com/watch?v=_smgvbxFu1M
FAQ
1. Are you manufacturer?
Yes, we are manufacturers. We have been in PC/POS/Mobile Payment product & Solution for Eight years. We can provide OEM / ODM customized service according to our customers' various application and demands.
2. Would you provide SDK for me?
Yes, we offer free SDK if you order sample. All the contents in a CD ROM with sample together.
3. What warranty for the products?
According to our warranty policy, we will provide 12 months warranty time from the shipment date for our all products (Excluded the consumable parts). As for the mass order, we will provide certain proportion spare parts or RMA machine for local service.
4. What's the delivery time?
Generally, sample can be shipped in 2-3 working days after payment. For quantity, theleading time will be 1-4 weeks depend on exact quantity.
5. What the after sale service?
a. Our all products will provide 12 months warranty;
b. Enough stock spare parts for guarantee;
c. Professional engineers provide 7*24 online service; If required, our engineers ca
