HCC-POS890E Plus
HCCTG
USB LAN Receipt Printer 80mm with Auto Cutter POS Thermal Printer for Restaurant HCC-POS890E Plus
Advantages of Thermal Printing:
Speed: Thermal printers are exceptionally fast and ideal for high-volume tasks.
Cost-Effective: There is no need for ink or toner cartridges, so maintenance costs are low.
Durability: Resistant to fading and smudging, ensuring long-lasting documents
Features:
New look, classic design;
Support out of paper alarm, paper near end detection. Humanized design,automatic paper cutting;
Support 58 mm / 80 mm paper with;
Mutiple interfaces-USB, LAN.
Specification
Print Method | Thermal Line |
Resolution | 8 dots/mm(203 dpi), 576 dots/line |
Print Speed | 220mm/s |
Effective Print Width | 72mm / 48mm |
TPH | 50KM |
Self-defined Characters | Yes |
Graph Printing | Diagram, download bitmap supported |
Print Font | GB18030: 24 * 24 ASCII: 12 * 24, 7 * 9 |
Barcode | 1D: UPC-A, UPC-E, EAN-13, EAN-8, CODE39, ITF25, CODABAR, CODE93, CODE128 |
2D: PDF417, QRCODE, DATAMATRIX | |
Interface | USB+Ethernet |
Cash Drawer Control | DC24V, 1A, 6Pin RJ-11 Socket |
Power Supply(Adapter) | DC24V±10%, 2A |
Paper Type | Normal thermal paper 79.5mm * φ80,57.5mm* φ80 |
Paper Thickness | 0.06mm ~ 0.08mm |
Paper Installation | Drop-in Easy Loading |
Paper Cutting Method | Full Cut / Patrial Cut |
Command | ESC / POS |
Character Set | ASCII, GB18030(Chinese), BIG5, Codepage |
Dimension | 185mm * 150mm * 123mm(L * W * H) |
Cutter Life | 1,500,000 cuts |
Operation Temp / Humidity | 0℃~50℃/ 10%～80% |
Storage Temp / Humidity | -20℃~60℃ / 10%～90% |
