HS-2011 is an advanced barcode scanner that boasts exceptional scanning capabilities. It is designed to effortlessly read 1D and 2D QR barcodes at remarkable speeds, making it an ideal choice for businesses seeking efficient barcode scanning solutions. This scanner is not only compatible with multiple systems but also offers seamless integration with a wide range of software and operating systems, ensuring seamless operation across various platforms.
| Quantity: | |
|---|---|
HS-2011
HCCTG
What is a 2D Barcode Scanning Box?
A 2D Barcode Scanning Box is a device equipped with a 2D barcode scanner that can read two-dimensional barcodes, such as QR codes and Data Matrix codes. It captures the information encoded in these barcodes for various applications, including inventory management, retail, healthcare, and ticketing systems.
High Speed Embedded 2D Barcode Scanner for Retail POS HS-2011
The HS-2011 exhibits an exceptionally high linear barcode scanning rate, and it effortlessly handles a diverse range of scanning applications involving paper barcodes as well as barcodes displayed on electronic devices. Moreover, the HS-2011 is engineered to meet the rigorous scanning demands imposed by challenging conditions, delivering efficient and consistent performance even in complete darkness and extreme temperature ranges. It leverages solid-state technology and adheres to the most stringent exposure standards, ensuring resilience against shock and vibration.
Feature
Quickly and accurately identify 1D code and QR code
Green low power consumption
Rich application scenarios
Ergonomic design
Stable, precise, convenient, practical, and efficient
Specification
Performance parameter | |
Image Sensor | CMOS |
Pixel | 648*488 CMOS |
Illumination | White light led |
Reading code system | 2D:PDF417,QR Code,Data Matrix |
1D:Code128,EAN-8,EAN-13,UPC-E,UPC-A,Interleaved 2 of 5, Matrix 2 of 5,Industrial 25,Code 39, Codabar, Code 93, Code 11,MSI-Plessey,GS1-DataBar | |
Reading accuracy |
|
Bar code sensitivity | Tilt:±65°@ 0°Roll and 0° Skew |
Rotate:±360°@ 0°Pitch and 0° Skew | |
Deflection:±60°@ 0°Roll and 0° Pitch | |
Data interface | USB HID/KBW interface，USB virtual serial port interface,RS-232 interface |
Field of view | 28° horizontal and 21.5° vertical |
Typical reading depth of field | Code 39 5mil 6-8cm 15mil 4-15cm |
Physical parameter | |
Size (length * width * height) | 78.4*67.2*53.2mm |
Weight | 185.9g (including USB cable) |
Prompt mode | Buzzer,LED indicator |
Electrical parameters | |
Voltage | Operating 5VDC ± 5% |
Current | Working current 210mA Stand-by current 70mA |
Environmental parameters | |
Operating temperature | -20℃ ~ +50℃ (-4°F~122°F) |
Storage temperature | -40℃ ~ +70℃ (-40°F~176°F) |
Relative humidity | 5%~95% (no condensation) |
Accessories list | |
Data line | Cable (2m) USB(HID-KBW,Virtual serial port) and RS232 interface at optional |
