HS-2011 is the cutting-edge barcode scanning solution, stands out for its exceptional ability to effortlessly read both 1D and 2D QR barcodes with remarkable speed and accuracy. Its advanced technology ensures swift and efficient scanning, making it the ideal choice for businesses and industries requiring rapid data capture.
| Quantity: | |
|---|---|
HS-2011
HCCTG
High Speed Embedded Barocde Module 2D Barcode Scanning Box HS-2011
HS-2011 stands out with its exceptional scanning capabilities, boasting an exceptionally high scanning rate for linear barcodes. Whether dealing with paper barcodes or those displayed on screens, HS-2011 effortlessly scans and handles various applications, making it a versatile choice for diverse scanning needs.
Engineered to surpass even the most demanding requirements, HS-2011 delivers consistent scanning performance under challenging conditions, including complete darkness and across a wide temperature range. Its cutting-edge solid-state technology not only ensures swift and accurate scanning but also meets the strictest standards for exposure, shock, and vibration, guaranteeing durability and reliability in any environment.
Feature
Quickly and accurately identify 1D code and QR code
Green low power consumption
Rich application scenarios
Ergonomic design
Stable, precise, convenient, practical, and efficient
Specification
Performance parameter | |
Image Sensor | CMOS |
Pixel | 648*488 CMOS |
Illumination | White light led |
Reading code system | 2D:PDF417,QR Code,Data Matrix |
1D:Code128,EAN-8,EAN-13,UPC-E,UPC-A,Interleaved 2 of 5, Matrix 2 of 5,Industrial 25,Code 39, Codabar, Code 93, Code 11,MSI-Plessey,GS1-DataBar | |
Reading accuracy |
|
Bar code sensitivity | Tilt:±65°@ 0°Roll and 0° Skew |
Rotate:±360°@ 0°Pitch and 0° Skew | |
Deflection:±60°@ 0°Roll and 0° Pitch | |
Data interface | USB HID/KBW interface，USB virtual serial port interface,RS-232 interface |
Field of view | 28° horizontal and 21.5° vertical |
Typical reading depth of field | Code 39 5mil 6-8cm 15mil 4-15cm |
Physical parameter | |
Size (length * width * height) | 78.4*67.2*53.2mm |
Weight | 185.9g (including USB cable) |
Prompt mode | Buzzer,LED indicator |
Electrical parameters | |
Voltage | Operating 5VDC ± 5% |
Current | Working current 210mA Stand-by current 70mA |
Environmental parameters | |
Operating temperature | -20℃ ~ +50℃ (-4°F~122°F) |
Storage temperature | -40℃ ~ +70℃ (-40°F~176°F) |
Relative humidity | 5%~95% (no condensation) |
Accessories list | |
Data line | Cable (2m) USB(HID-KBW,Virtual serial port) and RS232 interface at optional |
