Printing Method | Thermal |
Paper Type | Normal Thermal Paper / Thermal Label Paper / Blackmark Paper |
Print Head DPI | 203DPI |
Print Speed | 152 mm/s(max) |
Paper Width | 112 ± 0.5 mm |
Printing Length | 1778 mm(max) |
Interface | USB, Bluetooth / Wifi at optional |
Emulation | TSPL, ZPL, CPCL, DPL, EPL |
Sensor | Gap sensor/open cover sensor/Black label sensor |
SDRAM | 8MB |
FLASH | 8MB (expandable) |
Driver Support System | Windows:Windows 7/10/11(32 bit/64 bit) Macos: 10.9/10.10/10.11/10.12/10.13/10.14/10.15/11.6/12.1/12.2/ 12.3/12.4/14.4/14.6 Linux Ubuntu: 18.04/20.04/22.04/24.04 Astra Linux Special Edition V1.6 |
APP Support System | Android 6.0 and above, iOS 11 and above |
Bar Code Format | Code128, EAN128, ITF, Code39, Code93, EAN13, EAN13+2. EAN13+5, EAN8, EAN8+2, EAN8+5, CodeBar, Postnet, UPC-A.UPC-A+2, UPC-A+5, UPC-E, UPC-E+2, UPC-E+5, MSI, MSIC, PLESSEY, CPOST, ITF14, EAN14, Code11 |
Two-dimensional Code Format | QR code, PDF417, Micro PDF 417, DataMatrix, AZTEC |
Character Enlargement / Rotation | 1-10x magnification /0°, 90°, 180°, 270° rotation/mirror printing |
Character | GB18030, BIG5, ASCII |
Extended Character | PC437,Katakana, PC850, PC860, PC863, PC865, West Europe, Greek.Hebrew, East Europe, lran, WPC1252, PC866, PC852, PC858, lranl, Latvian, Arabic, PT151, PC747, WPC1257 and other languages, 61 kinds in total |
Character Size | 9 * 17dot,12 * 24dot ,24 * 24dot |
Roll Width | 30~114 mm (including backing paper) |
Roll Thickness | 0.12~0.26 mm (including backing paper) |
Paper Axis Size | 25.4 mm |
Roll Outside Diameter | 120 mm(OD) |
FEED | Front exit |
Power | Input power supply: AC100~240V Output power: DC 24V~2.5A |
Working Environment | Operating temperature: 5~40°C Operating humidity: 25~85% |
Storage Environment | Storage temperature: -10~60°C Storage humidity: 10~90% |
Print Head Life | 150 km (print rate 18.5%) |
Dimension | 210 * 168.5 * 152.5 mm |
Certification | CCC, CE, ROHS, REACH, TELEC (Japan), EAC (Russia), FAC (Russia), SRRC, BIS (India) |
Accessories (Standard) | |
