HM20-DC supports windows(XP,7,8,10), Linux operating system and also can connect to any Wiegand input controller.
| Quantity: | |
|---|---|
HM20-DC
HCCTG
HM20-DC QR code access card reader is our new intelligent access card reader, it's fast reading speed, high recognition rate, strong compatibility, single-door access control + 2d code scanner engine + the second generation ID card reader.
This 2D barcode reader can be embedded in any device for scanning code to identify other items, by using the intelligent image recognition algorithm.
Specification
Card type | EM or MifareEM (125KHZ)+Mifare/ Ntag 203\213(13.56MHZ) |
Code Type | QR Code, 2D |
Interface | Wiegand26/34, RS232,USB,RS485,TTL |
Decode mode | Image decoding |
Reading directions | Camera centric slant 45° |
Reading feature | Auto-induction & beeper |
Voltages | 4-12V Wide voltage input |
Current | 800mA |
Reading range of range | 3-6CM |
Reading speed | ＜200ms |
Reading range of QR | 0-20CM |
Materialcase | PC & temperrd glass |
Humidity | 10%~90% |
Temperature | -20℃~70℃ |
Operate system | Windows(XP,7,8,10), Linux |
Size | 86mm×86mm×42mm |
Status light | Red-work,Green-feedback,Light Green-internet |
Wight | 150G |
Remark | Use sharp objects inserted into RESET hole of QR code reader backside, release till the QR code reader automatically restarted. |
HM20-DC QR code access card reader is our new intelligent access card reader, it's fast reading speed, high recognition rate, strong compatibility, single-door access control + 2d code scanner engine + the second generation ID card reader.
This 2D barcode reader can be embedded in any device for scanning code to identify other items, by using the intelligent image recognition algorithm.
Specification
Card type | EM or MifareEM (125KHZ)+Mifare/ Ntag 203\213(13.56MHZ) |
Code Type | QR Code, 2D |
Interface | Wiegand26/34, RS232,USB,RS485,TTL |
Decode mode | Image decoding |
Reading directions | Camera centric slant 45° |
Reading feature | Auto-induction & beeper |
Voltages | 4-12V Wide voltage input |
Current | 800mA |
Reading range of range | 3-6CM |
Reading speed | ＜200ms |
Reading range of QR | 0-20CM |
Materialcase | PC & temperrd glass |
Humidity | 10%~90% |
Temperature | -20℃~70℃ |
Operate system | Windows(XP,7,8,10), Linux |
Size | 86mm×86mm×42mm |
Status light | Red-work,Green-feedback,Light Green-internet |
Wight | 150G |
Remark | Use sharp objects inserted into RESET hole of QR code reader backside, release till the QR code reader automatically restarted. |
